Alarm contact enclosure
Product Details
Product Details
1. Application
SD alarm contact for AC 50Hz, conventional heat current to 4a, circuit of 230V or DC rated voltage to 110V, CQB5A circuit breaker assembly, long distance circuit breaker on-off signal to indicate use.
Standard Number: GB 14048.5, IEC 6094 7-5-1.
2. Technical Data
Model | Version | |
AC-15 Series | Rated Voltage (V): | AC 230 V |
Rated Current (A): | 6 A | |
DC-13 Series | Rated Voltage (V): | DC 110 Volt |
Rated Current (A): | 1 A | |
Life | 10000 | |
3. Operation and installation conditions.

3.1 Ambient temperature: from -40 ℃ to 40 ℃
3.2, Relative humidity: ≤90% / 20 ℃, ≤50% / 40 ℃
3.3 Altitude is less than 2000m
4. Overall and mounting dimensions (mm)
